- Two 30V/1.5A (45W) channels and a 6V/5A (30W) channel on output supply
- All channels are independently controlled and have isolated outputs for maximum flexibility
- All channels have remote sensing to ensure that programmed voltage is accurately applied to the load
- Two 30V channels can be combined either in series to double output voltage or in parallel to double output current
- 0.03% basic voltage output accuracy and 0.1% current accuracy ensure quality test data
The Keithley 2220G Multi-Channel Programmable DC Power Supplies combine two channels of output power to cost-effectively characterize and test a wide range of devices, circuit boards, modules, and products that require more than one power source. The Keithley 2220G-30-1 supplies provide two channels, with each channel capable of outputting up to 30V and up to 1.5A. The Keithley 2220G-30-1 multi-channel power supplies offer an excellent combination of performance, versatility, and ease of use to maximize the information from characterization or test as quickly and as easily as possible. They perform as effectively in automated test systems as they do in manual instrument configurations. The USB interface is standard on all models; the “G” versions add a GPIB interface. | Independent and Isolated Outputs - Since each channel in the Keithley 2220G-30-1 multi-channel power supplies is completely independent and isolated from each other, the Keithley 2230G-30 power supplies can be used to provide power to two circuits that are optically isolated or transformer-isolated from each other and have different reference points. Their isolated channels eliminate the need for a second power supply to power one of the isolated circuits. | Additionally, each channel can be independently controlled, so channels can be individually turned on and turned off at any time. Thus, these power supplies can be used to power up a circuit with multiple voltage levels (such as a digital circuit) that must be turned on in a specified time sequence. Furthermore, the timer capability allows you to set up unattended tests that turn off the channels after a programmed time interval to protect a device-under-test (DUT) from potential damage due to the continuous application of power beyond a recommended time interval. Both isolated and independent channels provide excellent versatility and flexibility to address a wide range of test applications.
- Item Weight : 24.5 Pounds
- Date First Available : December 15, 2014
- Manufacturer : Keithley
